AO-BOX-0 - ACI
Automation Field Components
8 Channel Analog Output Module, Q-Controller
This item is temporarily out of stock.
It can be backordered right now, and we can ship it within 5 weeks.
0
138900
ACI
U.S.A.
{{CMP.TITLE}}
- Features
- Comments (0)
-
Data Sheet
AO-BOX-0 - ACI
Automation Field Components
download pdfPlease contact us if you need any other document this item may have.
You can only download Technical Document (Datasheet) on this section.
The AO-Box Model is 12-bit analog output modules designed for use with the QController control system. Each AO-Box module has 8x 4-20 mA output channels that provide 4-20mA signal as inputs to other host control devices.
The AO-Box and other IO-Box modules connect and communicate via a RS-485 2-wire connection to the Q-Controller. The QController supports any combination of the IO Box, the AO-Box can be up to 16 modules,allowing a total of 128 4-20mA analog signals
to be output via a single Q-Controller. All AO-Box configuration information is strored in Q-Controller and the 4-20mA calibration data is stored locally within the module, so replacement modules do not need to be configured and calibrated. The AO-Box’ high density packaging, removable terminal block and DIN rail mounting saves time and panel space. The module snaps easily onto standard top hat (T) profile DIN rail.Warranty :This product is under warranty for 2 years against manufacturing and material defects from the date of invoice. The invoice for the products also stands in place of the warranty certificate, a separate document is not issued.Delivery Information :ACI branded products are imported from United States of America factory specially to order. The estimated delivery time of the products is 5 weeks. In this product group, an additional shipping and customs fee of 450EUR is charged for orders under 4,000EUR.
