TUCH2-CPF11FZPSX-310XXXXXX - ACI
Automation Field Components
LCD, RH3%, SET, O/R, DEG F
This item is temporarily out of stock.
It can be backordered right now, and we can ship it within 5 weeks.
0
133751
ACI
U.S.A.
{{CMP.TITLE}}
- Features
- Comments (0)
-
Data Sheet
TUCH2-CPF11FZPSX-310XXXXXX - ACI
Automation Field Components
download pdfPlease contact us if you need any other document this item may have.
You can only download Technical Document (Datasheet) on this section.
The A/TUCH2 Series is a customizable sensor that utilizes an on-board microprocessor and capacitive sensing element with built in hygroscopic filter designed to protect the RH sensor from moisture and chemicals while delivering a resistive temperature and a proportional analog RH Output signal. This series includes a large backlit LCD Display which can be used to monitor your space temperature, relative humidity, set points, override and local system status when using the Override Feedback option. These units are factory configured to your desired specifications to reduce onsite programming. Additional features can be modified using the integral keypad and internal menu system, providing you with the flexibility required to meet your customers additional requests. These features include additional Set Point configurations, Backlight Display brightness and functionality, Set Point Lockout, Direct and Reverse Acting Output adjustments, temperature and humidity offsets, test functions and more. For additional features including Fan Speed and System Configurations, please contact KONTROLYUM for more information.
Applications: Schools and Universities, Offce Buildings, Commercial Buildings, Labs, Hospitals, Clean Rooms, Pharmaceutical, Process Control, OEM’s
The ACI TUCH2 Series is covered by ACI's Five (5) Year Limited Warranty. The warranty can be found in the front of ACI's Sensors & Transmitters catalog, as well as on ACI's website, Www.Workaci.Com.
Warranty :This product is under warranty for 2 years against manufacturing and material defects from the date of invoice. The invoice for the products also stands in place of the warranty certificate, a separate document is not issued.Delivery Information :ACI branded products are imported from United States of America factory specially to order. The estimated delivery time of the products is 5 weeks. In this product group, an additional shipping and customs fee of 450EUR is charged for orders under 4,000EUR.
