EX2432D - ACI
Automation Field Components
Wireless, Sensor Receiver, Expansion Module, 4 Digital & 4 Analog Outputs
This item is temporarily out of stock.
It can be backordered right now, and we can ship it within 5 weeks.
0
130696
ACI
U.S.A.
{{CMP.TITLE}}
- Features
- Comments (0)
-
Data Sheet
EX2432D - ACI
Automation Field Components
download pdfPlease contact us if you need any other document this item may have.
You can only download Technical Document (Datasheet) on this section.
The EX2432D Output Expansion Module provides 4 additional analog outputs and 4 additional digital outputs to the RM2432 Receiver. These wireless devices utilize reliable Spread Spectrum Mesh Network Radio technology. Together with other ACI wireless sensors and controls, the system can be used to transmit remote sensor readings, status/alarm indications and control signals wirelessly. It is compatible with any control systems or DDC panels that accept 0-10 VDC or 0-5 VDC inputs. A maximum of 2 EX2432 can be used with one RM2432 receiver. Up to 12 analog outputs and 12 digital outputs when two EX2432Ds are connected to the RM2432 Receiver. RR2552 signal repeaters can be installed as needed to increase transmission distance between sensors and receivers. ACI wireless sensors and systems are designed for retrofit HVAC, Building Automation, and industrial systems. Typical applications include: churches, museums, historical sites, etc. They are also suitable for flexible office/work station lay outs, auditoriums and conference centers with movable walls, or wide open warehouse spaces.
PLEASE NOTE: ONE CK2432 MUST BE PURCHASED TO PROGRAM THIS DEVICE. ONE CABLE CAN BE PURCHASED FOR MULTIPLE UNITS.
Click here: http://www.workaci.com/content/ck2432d
- Data Link LEDs confirm data transmission
- ACI can provide additional set up support before shipping
Warranty :This product is under warranty for 2 years against manufacturing and material defects from the date of invoice. The invoice for the products also stands in place of the warranty certificate, a separate document is not issued.Delivery Information :ACI branded products are imported from United States of America factory specially to order. The estimated delivery time of the products is 5 weeks. In this product group, an additional shipping and customs fee of 450EUR is charged for orders under 4,000EUR.
