ACUCT-S77-100:333 - ACI
Automation Field Components
Current Transformer, 100A, Solid Core, Measure Canada Approved, 0.77" Aperture, 333mV Output, 1ft Leads
This item is temporarily out of stock.
It can be backordered right now, and we can ship it within 5 weeks.
0
148212
ACI
U.S.A.
{{CMP.TITLE}}
- Features
- Comments (0)
-
Data Sheet
ACUCT-S77-100:333 - ACI
Automation Field Components
download pdfPlease contact us if you need any other document this item may have.
You can only download Technical Document (Datasheet) on this section.
The Solid-Core S77 High Accuracy Current Transformers are designed to convert an AC operating current into a low voltage AC millivolt signal for use with microprocessor-based circuits. These compact and light-weight solid-core current transformers are designed for installation on branch circuits for meter installations that require exceptionally accurate signal transformation. The S77 current transformer has been approved by Measurement Canada to be used in metering applications for installations used for billing purposes. CTs come standard unterminated stripped and tinned lead wires for easy connection to any of the Single or 3 Phase ACI power meter. CT models listed here are compatible with the ACI KW350-P1-D-S-SC, KW320-P1-D-W-SC-XX, KW320-P1-D-W-SC-PC, KW1850-P1-D-W, and KW1850-P1-D-S Power Meters where typical power measurements are required. For best accuracy, CTs should be selected based upon the expected maximum and minimum currents for the targeted application. The acceptable Measurement Current Range is referenced in the ordering grid table.
Warranty :This product is under warranty for 2 years against manufacturing and material defects from the date of invoice. The invoice for the products also stands in place of the warranty certificate, a separate document is not issued.Delivery Information :The stock quantity information reported in the product details is up to date. Products in stock can be shipped immediately. Products that are not in stock and whose delivery time is separately reported are shipped when the supply period is completed.
